TIG SERIES DC INVERTER TIG/MMA WELDING MACHINE
产品特点
FEATURES
● Adopt advanced MOSFET technology,energy-saving.
● Two functions of TIG/MMA,economic and practical.
● HF arc starting,stable current,the first choice for thin plate welding.
● With perfect over-current and over voltage protection function,safty and durable.
● Mainly used in welding carbon steel,stainless steel,alloy steel and copper.
● Accessories:TIG torch,electrode holder,earth clamp,brush/hammer,protective mask,carton box.
| Item | TIG-160 | TIG-180 | TIG-200 |
| Input Voltage(V) | 1PH 220 | 1PH220 | 1PH220 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 5.3 | 6.2 | 7.1 |
| Max No-load Voltage(V) | 60 | 60 | 60 |
| Current Range(A) | 10-160 | 10-180 | 10-200 |
| Rated Duty Cycle | 60% | 60% | 60% |
| Insulation Class | F | F | F |
| Rated work voltage(V) | 26.4/MMA | 27.2/MMA | 28/MIMA |
| Efficiency | 85% | 85% | 85% |
| Power Factor | Cosφ0.93 | Cosφ0.93 | Cosφ0.93 |
| Protection Degree | IP21S | IP21S | IP21S |
| Cool Type | fan | fan | fan |
| Dimension(mm) | 485x235x330 | 485x235x330 | 485x235x330 |
| Weight(kg) | 9.2 | 9.2 | 9.3 |
