MIG SERIES DC INVERTER DUAL-PULSE MIG/MMA/LIFT TIG WELDING MACHINE
产品特点
FEATURES
● Gas and gasless type
● Adopt IGBT technology, energy-saving.
● Anti-stick, thermostatic protection, less splash.
● High efficiency, light, compact, easy to operate.
● Suit for various welding rods, mainly use in welding aluminium, carbon steel, stainless steel, alloy steel and cast iron.
● Accessories: electrode holder, earth clamp, MIG torch brush / hammer, protective mask, carton box.
| Item | MIG-160M | MIG-180M | MIG-200M | MIG-250M |
| Input Voltage(V) | 1PH-220 | 1PH-220 | 1PH-220 | 1PH220V |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | MIG.4.5 | MIG:5.2 | MIG:6.1 | MIG:8.4 |
| MMA:4.6 | MMA:5.3 | MMA:5.8 | MMA:9.1 | |
| TIG:2.8 | TIG:3.3 | TIG:3.6 | TIG:3.6 | |
| No-load Voltage(V) | 56 | 56 | 56 | 60 |
| Current Range(A) | MIG:50-160 | MIG.50-180 | MIG:50-200 | MIG:50-250 |
| MMA:10-140 | MMA:10-160 | MMA:10-170 | MMA:10-220 | |
| TIG:10-140 | TIG:10-160 | TIG:10-170 | TIG:10-220 | |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 |
| Welding Wire(mm) | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 |
| Insulation Class | H | H | H | H |
| Protection Degree | IP21S | IP21S | IP21S | IP21S |
| Dimension(mm) | 580x350x450 | 580x350x450 | 580x350x450 | 845x425x775 |
| Weight(KG) | 11.5 | 12 | 12 | 12.5 |
