MIG SERIES IGBT INVERTER MIG/MMA/LIFT TIG WELDING MACHINE
产品特点
FEATURES
● Adopt with advanced IGBT inverter technology.
● 3 in 1 welding machine(MIG/MMA/LIFT TIG)
● Inverter MIG welder,High rated duty cycle with high effiency,
● Little welding spatter,deep welding pool,beautiful welding seam.
● Accessories:MIG torch,Electrode holder,earth clamp,brush/hammer,protective mask,carton box.
| ltem | MIG-250 | MIG·300 | MIG-250 | MIG-300 |
| Input Voltage(V) | 1PH220V | 1PH 220V | 3PH 380V | 3PH 380V |
| Freguency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(kva) | 10.7 | 14 | 8.4 | 11 |
| Poer factor | 0.73 | 0.73 | 0.93 | 0.93 |
| Max No-load Voltage(v) | 60 | 60 | 60 | 60 |
| Current Range(A) | 50-250 | 50-300 | 50-250 | 50-300 |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 |
| Usable Electrode(mm) | 0.6-1.0 | 0.6-1.2 | 0.6-1.0 | 0.6-1.2 |
| Insulation Class | H | H | H | H |
| Protection Degree | IP21S | IP21S | IP21S | IP21S |
| Dimension(mm) | 845x425x775 | 845x425x775 | 845x425x775 | 845x425x775 |
| Weight(kg) | 41.5 | 42 | 415 | 42 |
