TIG SERIES DC INVERTER TIG/MMA WELDING MACHINE
产品特点
FEATURES
● Adopt advanced IGBT technology,energy-saving.
● Two functions of TIG/MMA,economic and practical.
● HF arc starting,stable current,the first choice for thin plate welding.
● With perfect over-current and over voltage protection function,safty and durable.
● Mainly used in welding carbon steel,stainless steel,alloy steel and copper.
● Accessories:TIG torch,electrode holder,earth clamp,brush/hammer,protective mask,carton box.
| Item | TIG-160 | TIG-180 | TIG-200 | TIG-250 |
| Input Voltage(V) | 1PH220 | 1PH220 | 1PH220 | 1PH 220V |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 5.3 | 6.2 | 7.1 | 8.1 |
| MaxNo-load Voltage(V) | 60 | 60 | 60 | 56 |
| Current Range(A) | 10-160 | 10-180 | 10-200 | 50-250 |
| Rated Duty Cycle | 60 | 60 | 60 | 60 |
| Insulation Class | H | H | H | H |
| Eficiency | 85% | 85% | 85% | 85% |
| Power Factor | Cosφ0.93 | Cosφ0.93 | Cosφ0.93 | Cosφ0.93 |
| Protection Degree | IP21S | IP21S | IP21S | IP21S |
| Cool Type | Fan | Fan | Fan | Fan |
| Dimension(mm) | 450x260x330 | 450x260x330 | 450x260x330 | 480x205x380 |
| Weight(kg) | 7.4 | 7.4 | 7.5 | 7.5 |
