WSME SERIES AC DC INVERTER TIG/MMA WITH PULSE WELDING MACHINE
产品特点
FEATURES
● Adopt advanced IGBT technology, energy-saving.
● With PWM pulse width modulation technology,HF arc starting,stable current,the first choice for thin plate welding.
● With perfect over-current and over voltage protection function, safty and durable.
● Mainly used in welding carbon steel,stainless steel,alloy steel and copper.
● Accessories:TIG torch,electrode holder,earth clamp,brush/hammer,prtective mask,carton box.
● AC/DC convert switch,foot padel controller connection facility for welder's operation.
| ltem | WSME-250 | WSME-315 | WSME-400 |
| Input Voltage(V) | 3PH 380 | 3PH 380 | 3PH380 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 6.3 | 9 | 18.2 |
| Max No-load Voltage(V) | 60 | 60 | 60 |
| Current Range(A) | 20-250 | 20-315 | 20-400 |
| Rated Duty Cycle | 60% | 60% | 60% |
| Insulation Class | F | F | H |
| Rated work voltage(V) | 20 | 22.6 | 22.6 |
| Efficiency | 85% | 85% | 85% |
| Power Factor | Cosφ0.8 | Cosφ0.8 | Cosφ0.8 |
| Protection Degree | IP21S | IP21S | IP21S |
| Cool Type | Fan | Fan | Fan |
| Dimension(mm) | 600x390x450 | 600x390x450 | 600x390x450 |
| Weight(kg) | 38 | 40 | 42 |
