WSE SERIES AC DC INVERTER TIG/MMA WELDING MACHINE
产品特点
FEATURES
● Adopt advanced IGBT technology,energy-saving.
● Two functions of TIG/MMA,economic and practical .
● With PWM pulse width modulation technology,HF arc starting,stable current, the first choice for thin plate welding.
● With perfect over-current and over voltage protection function,safty and durable.
● Mainly used in welding carbon steel,stainless steel,alloy steel and copper.
● Accessories:TIG torch,electrode holder,earth clamp,brush/hammer,protective mask,carton box.
| Item | WSE-160 | WSE-180 | WSE-200 |
| Input Voltage(V) | 1PH 220 | 1PH220 | 1PH220 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 4.2 | 5 | 5.8 |
| Power Factor | 0.73 | 0.73 | 0.85 |
| Efficiency | 0.85 | 0.85 | 0.85 |
| Max No-load Voltage(V) | 56 | 56 | 56 |
| Current Range(A) | 10-160 | 10-180 | 10-200 |
| Impulse Frequency | 20-200HZ | 20-200HZ | 20-200HZ |
| Duty Cycle | 60% | 60 | 60% |
| Insulation Class | H | H | H |
| Protection Degree | iP21S | IP21S | IP21S |
| Dimension(mm) | 410x180x300 | 410x180x300 | 410x180x300 |
| Weight(kg) | 10 | 10.3 | 10.3 |
