BX1 SERIES TRANSFORMER AC ARC WELDING MACHINE

Categories:

AC ARC

Keys:

AC ARC

+86-576-86470117

lcf@tzfeida.com

Feedback
Contact

产品特点

FEATURES
● Portable,fan-cooled stick electrode.
● Stepless regulation of welding current with termal protection.
● Suitable 220/380V AC supply,various plug for your choosing.
● Accessories:electrode holder,earth clamp,brush/hammer,protective mask,carton box.







ltem BX1-130 BX1-160 BX1-180 BX1-200 BX1-250
Input Voitage(V) 220 220 220 220 220
No-load Voltage(V) 48 48 48 48 48
Current Range(A) 55-130 60-160 65-180 70-200 75-250
Rated Duty Cycle 10% 10% 10% 10% 10%
Input Capacity(KVA) 6.5 8 9.5 10.5 13.2
Protection Degree IP21 IP21 IP21 IP21 IP21
Insulation Class H H H H H
Usable Electrode(mm) 1.6-3.2 2.0-4.0 2.0-4.0 2.0-4.0 2.0-5.0
Weight(kg) 17.5 18.5 19.5 21.5 22.5
Dimension(mm) 480x270x320 480x270x320 480x270x320 480x270x320 480x270x320
