BX1 SERIES TRANSFORMER AC ARC WELDING MACHINE
产品特点
FEATURES
● Single phase,with wheel,fan cooling,heavy duty.
● With moving-iron core transformer,stable arc,high efficiency.
● Professinal welding in Alernating Current(AC),stepless regulation of welding current,suit for various electrodes
| ltem | BX1-160 | BX1-200 | BX1-250 | BX1-315 | BX1-400 | BX1-500 |
| Input Voltage(vV) | 380 | 380 | 380 | 380 | 380 | 380 |
| No-load Voltage(V) | 55 | 55 | 60 | 65 | 70 | 74 |
| Current Range(A) | 60-160 | 60-200 | 50-250 | 60-315 | 80-400 | 100-500 |
| Rated Duty Cycle | 20% | 20% | 35% | 35% | 35% | 35% |
| Input Capacity(KVA) | 9.2 | 11.5 | 15.7 | 21.4 | 29.4 | 38.5 |
| Protection Degree | F | F | F | F | F | F |
| Insulation Class | 2-4 | 2-4 | 2-5 | 2-6 | 2.5-8 | 2.5-10 |
| Usable Electrode(mm) | 1.6-8.0 | 1.6-8.0 | 1.6-10 | 1.6-10 | 2.5-12 | 2.5-14 |
| Weight(kg) | 58 | 63 | 69 | 74 | 82 | 92 |
| Dimension(mm) | 590x450x650 | 630x490x700 | 630x490x700 | 635x495x705 | 635x495x705 | 715x520x790 |
