IGBT SERIES DC INVERTER MMA WELDER
产品特点
FEATURES
● 3 PCB
● Adopt IGBT technology, energy-saving.
● Anti-stick,thermostatic protection, less splash.
● High efficiency, light, compact, easy to operate.
● Suit for various welding rods such as acidity, alkalescence and heat-resisting steel,mainly use in welding carbon steel, stainless steel, alloy steel and cast iron.
● Accessories: electrode holder, earth clamp, brush / hammer, protective mask, carton box.
| item | IGBT-250 | IGBT-315 |
| input Voltage(V) | 1PH220V | 1PH220V |
| Frequency(Hz) | 50/60 | 50/60 |
| Rated Input Capacity(KVA) | 9.5 | 13 |
| Povwer Factor | Cosφ0.93 | Cosφ0.93 |
| Max No-load Voltage(V) | 60 | 60 |
| Current Range(A) | 20-250 | 20-315 |
| Rated Duty Cycle(%) | 60 | 60 |
| Usable Electrode(mm) | 2.5-4.0 | 2.5-4.0 |
| Insulation Class | H | H |
| Protection Degree | IP21S | IP21S |
| Dimension(mm) | 460x270x330 | 485x255x435 |
| Weight(kg) | 10.5 | 13 |
