MSC SERIES DC INVERTER MMA WELDER/BATTERY CHARGER START
产品特点
FEATURES
● Single PCB
● Adopt IGBT technology,energy-saving,LCD
● Anti-stick,thermostatic protection, less splash.
● High efficiency, light, compact, easy to operate.
● Suit for various welding rods such as acidity, alkalescence and heat-resisting steel,
(MMA<VRD>)mainly use in welding carbon steel, stainless steel, alloy steel and cast iron.
(Battery charger/Start) Suitable for cars,vans,and light truck.
● Accessories: electrode holder, earth clamp, brush / hammer, protective mask, carton box.
| Item | MSC-200 | MSC-400 | MSC-600 | MSC-800 |
| Input Voltage(V) | 1PH 220V | 1PH 220V | 1PH220V | 1PH220V |
| Freguency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated Input Capacity(kva) | 5.3 | 7.1 | 10.2 | 12.1 |
| Power tactor | 0.73 | 0.73 | 0.73 | 0.73 |
| Max No-load Voltage(v) | 56 | 56 | 60 | 60 |
| Current Range(A) | 20-160(MMA) | 20-200(MMA) | 20-220(MMA) | 20-250(MMA) |
| Charging Voltage(V) | 12V/24V | 12V/24V | 12V/24V | 12V.24V |
| Charging Current(A) | 5-30 | 5-50 | 5-60 | 5-70 |
| Starting Current(A) | 200 | 400 | 600 | 800 |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 |
| Usable Electrode(mm) | 1.6-4.0 | 1.6-4.0 | 1.6-4.0 | 1.6-4.0 |
| Insulation Class | H | H | H | H |
| Protection Degree | IP21S | IP21S | IP21S | IP21S |
| Dimension(mm) | 410x180x300 | 410x180x300 | 410x180x300 | 410x180x300 |
| Weight(kg) | 4 | 4.5 | 5 | 6 |
