CUT SERIES PLASMA CUTTING MACHINE
产品特点
FEATURES
● Air plasma cutter for professional cutting in DC,two positions regulation of current,
● HF ARC starting with contact,usable curve cutting fleetly.
● High cutting speed,Narrow cutting gap,smooth cutting surface,small distortion.
● With perfect over-current, over-heat, over-voltage protection function, safety and durable.
● Widely use for cutting carbon steel,stainless steel,alloy steel, copper,aluminium and so on.
● Accessories: cutting torch,earth clamp,brush/hammer,protective mask,carton box.
| Item | LGK-63 | LGK-100 | LGK·120 |
| Input Voltage(V) | 3PH380 | 3PH 380 | 3PH380 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 |
| Max No-load Voltage(V) | 260 | 270 | 280 |
| Current Range(A) | 10-63 | 76-100 | 80-120 |
| Rated Duty Cycle(%) | 60 | 60 | 60 |
| Cutting Thickness(mm) | 18 | 28 | 34 |
| Air Pressure(Mpa) | 0.2-0.4 | 0.3-0.5 | 0.3-0.5 |
| Protection Degree | IP21S | IP21S | IP21S |
| Dimension(mm) | 720x450x660 | 850x520x710 | 850x520x710 |
| Welght(kg) | 20 | 21.5 | 22 |
