SC SERIES BATTERY CHARGER/STARTER
产品特点
FEATURES
● Portable battery charger for 12V/24V lead acid batteries.
● Thermal protection.
● Charging time setting with timer choossable.
● Equipped with ampere meter showing charging amp,
● digital display choossable
● Compact,light and portable.
● Suitable for cars,vans,and light truck.
| ltem | MA-30S |
| Input Voltage(V) | 1PH 220V |
| Freguency(HZ) | 50/60 |
| Rated Input Capacity(kva) | 1.2 |
| Power factor | 0.73 |
| Charging Voitage(V) | 12V/24V |
| Starting Current(A) | 150 |
| Charging Current(A) | 5-30 |
| Insulation Class | H |
| Protection Degree | IP21S |
| Dimension(mm) | 180x225x105 |
| Weight(kg) | 2.5 |
| Item | SC-300 | SC-600 |
| Input Voltage(V) | 220V/50HZ | 220V/50HZ |
| Working Voltage(V) | 170-255 | 170-255 |
| Rated boost capacity(KW) | 5.1 | 6.6 |
| Charging voltage(V) | 12/24 | 12/24 |
| Starting Current(A) | 250 | 550 |
| Charging Current(A) | 5-60 | 5-80 |
| Reference capacity Ah15h(min/max) | 25-800 | 25-800 |
| Weight(KG) | 3.5 | 4.8 |
| Dimension(MM) | 310x205x265 | 385x210x265 |
